Edelbrock Pro-Flo 4 EFI System for Chevy LS GEN III/IV engines. The EFI System comes with a 4150-Style satin finish Victor Jr. cathedral port intake and 35 Lb/Hr injectors capable of 550 HP with 58 p.s.i. fuel pressure.
The Edelbrock Pro-Flo 4 #35710 for Chevrolet LS GEN III/IV engines is equipped with the latest in technology and features. The EFI system comes complete with a traditional 4150-Style satin finish Victor Jr. cathedral port single plane intake manifold and 35 Lb/Hr injectors capable of 550 HP with 58 p.s.i. fuel pressure. The new Pro-Flo 4 EFI systems feature an all-new ECU with a faster processor, a water proof design and measures half the depth of the previous ECU. It also has an upgraded Bluetooth chip that is faster, more reliable and will not drop connection. We've added more features for the advanced tuner giving you control over air-fuel ratios, ignition curve, idle speed, acceleration fuel, coolant fans, Rev limiter while retaining the simplicity Pro-Flo is known for. The key to the system is our exclusive E-Tuner 4 app with dyno developed base calibrations. The E-Tuner 4 app uses a Bluetooth wireless connection to communicate with the ECU's self-learning capability to continually adjust the calibration to get the maximize performance of your engine. E-Tuner 4 features a simple and easy to use setup wizard to help you get started as well as multiple dash displays so you can monitor your engines vitals and performance. The exclusive Edelbrock E-Tuner 4 app is Free and Available for Android and IOS based smart phone or tablet.
Application Summary:
| Year |
Make/Model |
| 2007-2009 |
Chevrolet Avalanche |
| 2002-2006 |
Chevrolet Avalanche 1500 |
| 1997-1998 |
Chevrolet B7 |
| 1997-1998 |
Chevrolet C6500 Kodiak |
| 1997-1998 |
Chevrolet C7500 Kodiak |
| 2007-2013 |
Chevrolet Cheyenne |
| 2009-2012 |
Chevrolet Colorado |
| 2005-2007 |
Chevrolet Corvette |
| 2003-2009 |
Chevrolet Express 1500 |
| 2003-2005 |
Chevrolet Express 2500 |
| 2003-2005 |
Chevrolet Express 3500 |
| 2010-2013 |
Chevrolet Express Cargo |
| 2010-2013 |
Chevrolet Express Pasajeros |
| 2006-2009 |
Chevrolet Impala |
| 2006-2007 |
Chevrolet Monte Carlo |
| 1999-2009 |
Chevrolet Silverado 1500 |
| 2007 |
Chevrolet Silverado 1500 Classic |
| 1999-2000 |
Chevrolet Silverado 2500 |
| 2011-2013 |
Chevrolet Silverado 2500 |
| 2011-2013 |
Chevrolet Silverado 2500 HD |
| 2008-2013 |
Chevrolet Silverado 3500 |
| 2011-2013 |
Chevrolet Silverado 3500 HD |
| 2003-2004 |
Chevrolet SSR |
| 2000-2009 |
Chevrolet Suburban 1500 |
| 2011-2013 |
Chevrolet Suburban 1500 |
| 1997-1998 |
Chevrolet T6500 |
| 1997-1998 |
Chevrolet T7500 |
| 2000-2009 |
Chevrolet Tahoe |
| 2011-2013 |
Chevrolet Tahoe |
| 2006-2008 |
Chevrolet Trailblazer |
| 2003-2006 |
Chevrolet Trailblazer EXT |
| Attributes |
| Bore Diameter |
1.75 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Cathedral Port |
| Distributor Cap Included |
Yes |
| Emission Code |
Off Road |
| Engine Make/Size |
Chevy LS Series |
| Finish |
Satin, Satin, Satin |
| Flange Type |
4150 |
| Fuel Injector Type |
35 lb/hr, 35 lb/hr, 35 lb/hr |
| Fuel Pressure Port |
1/8-27 NPT, 1/8-27 NPT, 1/8-27 NPT |
| Fuel Rate |
35 lbs./hr |
| Gasket Or Seal Included |
Yes, Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Idle Air Control Motor Included |
Yes |
| Life Cycle Status Code |
Available to Order |
| Manifold Height |
4.95 |
| Maximum Horsepower |
550 |
| NAFTA Preference Criterion Code |
B |
| Quantity |
Kit, Kit, Kit |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| SDR Required Flag |
N |
| System Type |
Traditional 4150-Style Kit, Traditional 4150-Style Kit, Traditional 4150-Style Kit |
| Throttle Body Type |
4 Barrel, 4 Barrel, 4 Barrel |
| Warranty Time |
24 |
| Wire Harness Included |
Yes |
| Wiring Harness Included |
Yes, Yes, Yes |
| GTIN |
00085347357109 |
